Richtek Announces RT318xx Products Qualified as WPC Qi EPP Certified
Wireless Power Receiver and Transmitter |
|
Richtek is committed to the development of wireless charging solutions
after the completion of the merger with MediaTek. Since 2016, Richtek
has taken full ownership of all MediaTek's wireless power solution
business including product development and strategic planning. In
this issue, Richtek is proud to announce that both the RT3181A based
MPA5 wireless power transmitter solution and the RT3180W based wireless
power receiver solution are fully qualified as WPC Qi EPP (Extended
Power Profile) Certified Products. |
|
The WPC Qi standard has become a mature and widely adopted specification. Today’s power hungry mobile phones require higher charging power, so the EPP products with output power up to 15W have gradually gained in popularity in the growing wireless charging power market. In order to shorten time to market, Richtek WPC Qi EPP certified wireless modules can be directly placed into customer prototype designs. Unlike general testing evaluation boards with larger size optimized layouts, Richtek wireless modules are laid out in a tiny configuration which match small prototype dimensions, allowing quick prototype design without massive layout changes. The below pictures show examples of the actual applications. |
|
|
|
Since both BPP (Baseline Power Profile <5W) and EPP (Extended
Power Profile 5W-15W) qualifications share the same logo, the only
way to identify whether a WPC product is qualified as BPP or EPP
is by checking the official WPC website. All Richtek WPC Qi EPP
solutions are certified products so they are listed on the official
WPC website. It is crucial to avoid any compatibility problems or
confusion on products marked as ‘fast charging’ or ‘fast wireless
charging’ which may only be BPP certified. Please search the
WPC website and check the ‘power profile’ for EPP certification.
The examples of RT3181 based MPA5 EPP TX and BPP A11 TX are shown
below. |
|
RT3181 MP Charger |
RT3181 LP Charger |
 |
 |
|
|
In the booming wireless power market, we see an increasing demand
on EPP (5W-15W) charging products but power dissipation is always
a concern. |
Therefore, 10W is a moderate specification for system design
in MPA5 or MPA2 wireless transmitter base.
In terms
of wireless power system efficiency, the RT3181A in MPA5
base performs better than other manufacturers in the range
of 10W receiver output power. (Please see the diagram on
the right side) |
 |
|
|
For more wireless product information, please access
Richtek wireless
power solution application page or contact us: wps@richtek.com |
Want to know more about wireless charging?
Please watch
the videos of Richtek presentations during IEEE 2017 Wireless Power
Transfer conference in Taipei, Taiwan (May 12, 2017) |
|
The Wireless Power is in Charging |
Wireless Power Circuit Design and Solutions
|
|
This talk covers the wireless power standard and market
information. Two major wireless power standards, WPC and
Airfuel Alliance are introduced. Some applications and
RT3181 wireless power solutions are demonstrated as well. |
This talk covers the circuit design considerations and solutions
for magnetic resonant and magnetic inductive wireless power
transfer. Richtek RT3180 multi-mode RX solution and design
examples are also discussed. |
 |
 |
|
|
Upcoming event |
Richtek at Wireless Power Taipei
(Grand Mayfull Hotel Taipei, Taiwan, Aug 31st – Sep 1st, 2017)
|
 |
|
|
Richtek will host a talk to share our insights on wireless power solutions during the Qi developer conference (Aug 31st, 2017). We will also showcase a broad range of wireless power solutions including standard WPC transmitter/Receiver and medium power WPC modules in the wireless power tradeshow (Sep 1st, 2017). Please see
this link for further information. |
|
New Products |
 |
RT6210 is a 500mA, 80Vin, 350kHz Synchronous
Buck Converter in a SOP-8 package. Operating
in 5.2V-80V wide input and 0.8V-72V programmable
output, RT6210 features current mode control to
simplify external compensation and pulse-skipping
mode for enhanced light load efficiency. A great
choice for industrial process control, metering,
security systems, commercial vehicle power supplies,
telecom system, etc.
⇒
Also see other wide Vin products: RT6204 60Vin Buck
converter |
 |
RT9468 is a 5A single cell Li-ion switching
battery charger with Direct Charge, power path management
and USB OTG Boost mode in a WQFN-32L 4x4 package.
Targeted for space-limited portable applications,
it integrates a Direct Charge function and complete
protection functions. RT9468 has a single input
operating from 3.9V-14V in adapter mode or 3.0V-7V
in Direct Charge mode. The key charge parameters
are programmable via I2C.
⇒
Get Free RT9468 Sample Now
⇒
Also see other switching battery chargers |
 |
RT1711P is a USB Type-C and Power Delivery (PD)
Port Controller in a WQFN-24L 3.5x3.5 package.
Supporting USB PD3.0 and TCPC1.0, RT1711P integrates
a complete Type-C transceiver providing cable recognition
and orientation detection. It also integrates the
physical layer of the USB BMC power delivery protocol,
allowing up to100W of power transfer and role swap.
Ideal for portable devices, monitors, TVs, power
bank, etc.
⇒
Get Free RT1711P Sample Now |
 |
RT1716 is a programmable USB Type-C PD Controller
in a WL-CSP-8B 1.38x1.34 package. Supporting
PD 3.0 except fast role swap function, RT1716 is
dual-role PD compatible providing attach/detach
detection and orientation. It provides the physical
layer functionality of the USB-PD protocol suitable
for portable devices. |
 |
RT1730 is a programmable USB type-C Controller
in a WL-CSP-9B 1.38x1.34 (BSC) package.
With similar features to RT1716, RT1730 has an extra
regulated input VCONN pin to power the IC within
an electronically marked Type-C cable. |
 |
RTQ2522A/B is an industrial grade bias rail LDO with 2A current capability, low 0.8V-5.5V input and 0.8V-3.6V output range and ultra-low dropout voltage in a WDFN-10L 3x3/WQFN-20L 5x5 package. Featuring High PSRR, Enable, PGOOD and programmable Soft-Start, RTQ2522A/B is capable of supplying 2A Iout with a low dropout voltage of 135mV. Ideal for industrial applications like Servers, FPGA, DSP Core and other post regulation applications.
⇒
Get Free RTQ2522A/B Sample Now
⇒
See LDO selection criteria |
|
|
|
|
